3-Inch Flush-Mount Combo-Beam Off-Road Light Kit
SKU: BF3-B6por
✓
3-Inch Flush-Mount Combo-Beam Off-Road Light Kit
SET+ Wire harness
SKU: BF3-B6por
Contact for Price
In stock
This 3-inch flush-mount combo-beam off-road light kit uses a pair of compact B-series six-optic lamps with a yellow center DRL bar and a supplied wiring harness. Its Spot + Flood beam designation combines forward-focused and broader auxiliary-lighting roles, while the flush-mount side-ear housing distinguishes it from the bracket-mount A-series version.
Confirmed catalog data includes 9–36V DC input, 17.8W rated power at 12V, 1.47A current draw, IP68/IP69K protection and a 3 m cable. The lamp uses six 5W CSP3535 main LEDs with six 0.5W SMD3030 DRL LEDs, with 2400 lm theoretical output and 1397 lm measured luminous flux. The aluminum flush-mount housing measures 120 × 89 × 45 mm, giving distributors and project buyers clear beam, electrical, mounting and kit-configuration data for comparison.
Voltage
9-36V DC
Rated Power
17.8W @ 12V
Current
1.47A @ 12V
LED Configuration
Main 6 × 5W CSP3535 + DRL 6 × 0.5W SMD3030
Beam Pattern
Spot + Flood
Light Color
White + Yellow
Theoretical Lumens
2400 lm
Measured Luminous Flux
1397 lm
IP Rating
IP68/IP69K
Operating Temperature
-40°C to 85°C
Cable Length
3 m
Certification
CE / ECE R10
Housing Material
Aluminum
Product Form
3-inch flush-mount square LED pod pair
Lamp Dimensions
120 × 89 × 45 mm
Mounting Type
Flush-mount side-ear housing
Product Configuration
Set + wiring harness
Package Size
240 × 225 × 85 mm
Gross Weight per Set
1300 g
Quantity per Carton
10 sets
Carton Size
470 × 470 × 260 mm
Carton Gross Weight
13.3 kg
